SPC Anti-Collision Wall Panel
SPC Anti-Collision Wall Panel (Stone Plastic Composite Impact Panel) is a new type of wall protection and decoration material, produced by high-temperature and high-pressure extrusion of natural calcium carbonate (stone powder) and PVC resin.It adopts a multi-layer structure: UV wear-resistant layer + decorative film layer + SPC solid core layer + optional IXPE/EVA silent underlayment.
Download
Product Description
Application Scenarios
Residential：Whole-house (living room, bedroom, kitchen, bathroom, balcony), kids' rooms, pet areas, first-floor damp-prone rooms, underfloor heating rooms.
Commercial:Hospital corridors, wards, nursing stations; school corridors, kindergartens; hotel lobbies & guestroom corridors; shopping malls, restaurants, gyms; nursing homes, office buildings.
Special Uses:Renovation projects, basement walls, elevator lobbies, parking garage wall protection.
Product Specifications
|
Parameter |
Specification Range |
Notes |
|
Thickness |
4mm, 6mm, 8mm, 9mm, 12mm |
|
|
Width |
600mm, 800mm, 1220mm |
Customizable |
|
Length |
2440mm, 2800mm, 3050mm |
Customizable |
|
Surface Finish |
Wood grain, marble, fabric, solid color, |
Various options |
|
Wear Layer |
0.1mm-0.5mm |
≥0.3mm for commercial use |
|
Fire Rating |
Class B1(self-extinguishing) |
Class A available for some grades |
|
Environmental |
ENF/EO |
Formaldehyde-free |
|
Silent Pad(Optional) |
IXPE or EVA, 1-2mm |
Reduces noise by 15-20dB |
Installation Methods
SPC impact panels are easy to install. Three main methods:
Click-Lock / Clip System (Recommended)
Panels are connected via click-lock or clips without adhesive, laid directly over flat walls or existing wall coverings. Suitable for most flat walls. A 100㎡ room can be completed in 1-2 days.
Adhesive Mount
Apply special structural adhesive (e.g., MS adhesive, construction adhesive) to the back of the panel and press onto the wall. Suitable for curved or irregular walls, or small areas.
Furring / Subframe Installation
For uneven walls, first install wooden or metal furring strips to level the surface, then fix the panels. Suitable for old walls or when wiring space is needed.
Installation Steps (Click-Lock System):
Clean wall surface – ensure it is dry, flat, and dust-free
Start from a corner; fix the first panel with screws or adhesive
Insert the next panel at a 45° angle into the lock, then tap down to secure
Continue panel by panel; finish edges with trim profiles
Clean the surface – installation complete
Summary
SPC anti-collision wall panel integrates safety, environmental protection, beauty and rapid installation in one. It is an ideal wall protection material for modern architecture.Whether for children’s rooms, humid kitchens and bathrooms, or high-flow public spaces such as hospitals and schools, SPC anti-collision panels provide durable and reliable wall protection, while upgrading the overall spatial aesthetics.
Key Advantages & Features
01 High Impact Resistance
SPC solid core and multi-layer structure absorb impact energy, preventing dents or cracks. Service life ≥15 years.
02 100% Waterproof & Moisture-Proof
Non-absorbent, no deformation or mold even after long-term soaking. Ideal for kitchens, bathrooms, basements.
03 Zero Formaldehyde & Eco-Friendly
Glue-free process, ENF/E0 certified. Safe for immediate occupancy.
04 Class B1 Fire Retardant
Self-extinguishing, no toxic smoke emission. Meets public building fire codes.
05 Wear & Scratch Resistant
UV/wear layer protects against daily furniture and pet claws.
06 Easy to Clean & Stain Resistant
Acid/alkali resistant, wipes clean with a damp cloth. No mold, no insects.
07 Noise Reduction
Optional silent pad reduces noise by 15-20dB.
08 Quick Installation
Click-lock / clip system, can be installed directly over old walls. Shortens installation time by over 50%.
Choose the Right Partner for Your Floor
SPC floors come in a variety of colors and patterns, including wood/marble/carpet patterns, so it's easy to find the right style for your business and project.
Applicable Scenarios
Residential Scenarios
Kids’ rooms, living room feature walls, bedroom walls, corridors, entryways, balconies, kitchen and bathroom dry areas.
Zero formaldehyde and eco-friendly, super impact resistance, suitable for families with the elderly and children; waterproof and easy to clean, solving the problem of moisture and mold in kitchens, bathrooms and balconies; rich patterns, enhancing home decoration grade.
Medical Facilities
Hospital wards, corridors, nurse stations, clinics, nursing homes, rehabilitation centers.
Zero formaldehyde, impact resistance (avoiding patient collision injuries), easy to clean and disinfect, Class B1 fire rating, meeting the hygiene and safety standards of medical facilities.
Kitchen & Bathroom
Kitchen walls, bathroom dry-area walls, balconies;
100% waterproof, mold-proof, easy to clean.
Commercial Spaces
Hotel guestrooms/lobbies, restaurants, cafes, milk tea shops, clothing stores;
Fast renovation, unified style, scratch-resistant.
Basements/Garages
Basement walls, garage walls, storage rooms;
Waterproof, moisture-proof, mold-resistant.
Public Facilities
Exhibition halls, museums, subway stations, waiting rooms;
Flat, aesthetic, durable, fast installation.
Educational Institutions
Kindergartens, primary school classrooms, corridors, stairwells, training centers, daycare centers;
Eco-friendly and safe, impact and scratch resistant (suitable for children's activity scenarios), easy to clean, childlike patterns, protecting children's safe growth.
Office Spaces
Office partitions, conference room walls, corridors, reception areas;
Waterproof, moisture-proof, mold-resistant.
SPC System Accessories Table
|
Category |
Material Name |
Integration Method / Application |
Core Advantages |
|
1. Substrates |
Magnesium Oxide Board (MgO Board) |
Fireproof substrate or composite backing for SPC wall panels. |
A2 Fire Rating; exceptional screw-holding strength. |
|
Base Layers) |
Calcium Silicate Board |
Base material for indoor partitions; SPC panels are laminated on the surface. |
High dimensional stability; moisture-proof; superior flatness. |
|
|
Fiber Cement Board |
Base layer for SPC integration in high-humidity or outdoor environments. |
High structural strength; weather and impact resistant. |
|
|
Oriented Strand Board (OSB) |
Sub-floor support for SPC flooring in "dry-construction" systems. |
Good structural integrity; adds underfoot resilience/elasticity. |
|
2. Functional Cores |
IXPE / EVA Foam Layer |
Pre-attached to the back of SPC flooring or integrated within wall panels. |
Excellent vibration damping; sound reduction (acoustic); comfort enhancement. |
|
(Core Layers) |
XPS / EPS Insulation Board |
Integrated with SPC to create "Thermal Insulation Wall Panels." |
Superior thermal insulation; significantly improves building energy efficiency. |
|
|
Aluminum Honeycomb Core |
Composite of thin SPC veneer with aluminum honeycomb for large-format panels. |
Significantly reduces weight while ensuring extreme flatness and rigidity. |
|
3. Complementary |
WPC (Wood Plastic Composite) |
Paired with SPC flooring/wall panels in indoor-outdoor transition zones. |
Natural wood-like texture; 100% waterproof; complementary aesthetics. |
|
Decorative Panels |
Polyester Fiber Acoustic Panels |
Alternated with SPC wall panels in studios or office spaces. |
Enhances acoustic performance; solves room reverberation issues. |
|
|
Brushed / Mirrored Metal Panels |
Used as edge trims, waistlines, or accent decorative features. |
Enhances modern, high-tech, and premium aesthetics. |
|
4. Structural |
Aluminum Composite Panel (ACP) |
Used for integrated ceilings or complex corner fabrications. |
Easy to bend and process; surface finish highly compatible with SPC. |
|
& Partitions |
Hollow Plastic Formwork |
Used as temporary or permanent support in modular building systems. |
Lightweight and easy to assemble with SPC quick-install systems. |
FAQ
Q: What are your main products?
Our core products include sound-absorbing panels, SPC boards, metal composite panels, flexible stone materials, PU (polyurethane) cultural stones, and supporting interior decoration materials.
Q: What payment methods do you offer?
We mainly accept T/T; Letter of credit.
Q: Samples and styles?
Our products are available in a wide range of styles and colors. Samples are available: usually free of charge, with customers only responsible for shipping costs. We support customization of color, size, pattern, and surface finish, producing according to your needs. New styles can be made for OEM/ODM, developing exclusive products for your market.
Q: Why should I choose your product?
Leveraging the dual advantages of our parent company's extensive engineering experience and our own factory, we not only provide products but also offer comprehensive solutions such as customized product combinations and technical consulting services. We strive to create safe, comfortable, and high-performance indoor spaces for global customers, enabling people to feel a stronger sense of security and belonging in their work and daily lives.
Q: How do you carry out quality assurance?
We have established a comprehensive quality control system spanning from raw material procurement to finished product shipment. All incoming raw materials undergo rigorous inspection. During the production process, real-time online inspections are conducted for dimensions, color, surface, thickness, and various properties. Before packing, spot checks are performed on the appearance, dimensions, flatness, strength, etc. of the finished products. Additionally, export-safe packaging using reinforced cardboard boxes and pallets is employed to effectively prevent damage during transportation.
